SKU: MP-10PH Category:

Optical System : Infinity corrected optical system.
Observation Head : Sidentopf Trinocular observation head inclined at 25/30° rotatable at 360°. Vertical phototube for micro photography. Diopter adjustment ring on ocular tube. (±5) Interpupillary distance from 50mm to 75mm. Observation and imaging at the same time.
Eyepiece : WF 10x eyepiece of 22mm F.O.V, anti-fungus treated. Centering telescope eyepiece 10x.
Nosepiece : Reverse angle sextuple nosepiece revolving on ball bearings with tilt backward.
Objective : Infinity Corrected anti mold, anti-fungus treated:
CCIS Plan PHASE Achromatic 10X N.A 0.25
CCIS Plan PHASE Achromatic 20X N.A 0.40
CCIS Plan PHASE Achromatic 40X (S.L.) N.A 30mm.
CCIS Plan PHASE Achromatic 100X Oil (S.L.) N.A 1.25
Mechanical Stage : Ceramic coated low drive Rackless Mechanical stage size 187mm x 167mm & having low positioned co-axial controls on ball bearing guide ways. Double specimen holder on left side for two slides. Moving range 75×50, Drive right and specimen holder for two slides with spring clips.
Condenser : Centrable Phase Annular Rings built inside matching with annular Phase plates provided in a substage condenser having a turret to bring in position the required Phase Rings suitable for the particular objective which is in position.
Focusing : Co-axial focusing control with large knob, pre-focusing lever & tension adjustment ring. Fine div 0.001mm, coarse stroke 37.7mm per rotation, Fine stroke 1micron/rotation .Moving range 25mm.
Illumination : Full Koehler illumination with transmitted light slide-in modules with 6V 30W halogen lamp and LED 3W white light, with LED with life of 5600 Hrs. Aspherical collector. Brightness control knob. Universal Power Supply 100 V to 240 V,AC 50-60 Hertz, CE Compliant.
Sub Stage Condenser: Swing out front lens, abbe condenser N.A. 0.9/1.25, Abbe condenser0.9/ 1.25 with slot for Slider H, Ph1, Ph2, Ph3 filter holder and iris diaphragm.
Standard Accessories: Dust cover, blue filter, guarantee card operating manual and Styrofoam molded pack.
Optional Accessories : Camera with software, Compatible PC.
Certifications : European CE certified.
Warranty : Two Years warranty. Extended warranty can be given on specific requirements.
