Model No. – MP-10 | Make – WESWOX |
- Optical System: Infinity corrected optical system.
- Obsevation Head: Sidentopf Trinocular observation head inclined at 30° rotatable at 360°. Vertical phototube for micro photography. Diopter adjustment ring on ocular tube. (±5) Interpupillary distance from 50mm to 75mm.
- Eyepiece : WF 10x eyepiece of 22mm F.O.V, anti-fungus treated.
- Nosepiece : Reverse angle sextuple nosepiece revolving on ball bearings.
- Objective: Infinity Corrected anti mold, anti-fungus treated:
- CCIS Plan Achromatic 2X N.A 0.06
- CCIS Plan Achromatic 4X N.A 0.15
- CCIS Plan Achromatic 10X N.A 0.25
- CCIS Plan Achromatic 40X (S.L.) N.A 0.65
- CCIS Plan Achromatic 100X Oil (S.L.) N.A 1.25
- Mechanical Stage: Ceramic coated low drive Rackless Mechanical stage size 187mm x 167mm & having low positioned co-axial controls on ball bearing guide ways. Double specimen holder on left side for two slides.
- Condenser: Swing out abbe condenser N.A. 0.9/1.25, filter holder and iris diaphragm for objcctives (2X-100x).
- Focusing : Co-axial focusing control with large knob, pre-focusing lever & tension adjustment ring. Fine div 0.001mm, coarse stroke 37.7mm per rotation, Fine stroke 1micron/rotation .Moving range 25mm.
- Illumination : Koehler’s illumination system with LED with life of 20000 Hrs. Aspherical collector. Brightness control knob. Universal Power Supply 100 V to 240 V,AC 50-60 Hertz, CE Compliant.
- Sub Stage Condenser: Swing out front lens, abbe condenser N.A. 0.9/1.25, filter holder and iris diaphragm.
- Standard Accessories: Dust cover, blue filter, guarantee card operating manual and Styrofoam molded pack.
- Optional Accessories : Upgradeable to Fluorescence Attachment at least 6 filter position on a turret at a time. Branded computer system with i7 processor, 8b ram, 1tb HDD, DVD R/R 21 inch, genuine window 10.
- Certifications : European CE certified.
Warranty: Two Years and One Year on electronics. Extended warranty can be given on specific requirements.
