SKU: FATP-1090A Categories: ,

Simultaneous processing up to 200 cassettes.
High quality specimen.
Fully automatic reagent management system with reagent bottle capacity between 3 to 4 liter.
Compherehensive monitoring and full process control.
Eight programs that consists of 9 reagent and 3 paraffin wax steps.
Large color LCD display.
One touch start of pre saved programs.
Reagent level alarm.
Automatic/ manual running modes.
Auto memorization and recovery.
Optional automatic fill and drain reagent system.
Auto cleaning cycle.
Low reagent alarm.
Agitation in retort.
Easy cleaning and maintenance.
Warning alarm for trouble free operation.
2 year warranty.
Extended warranty can be provided on request.


Number of baths: 3
Volume (liters): 4.0 l per bath
Melt time: approx. 3 hrs
Temperature: 65 ℃
Temperature accuracy: + 3 ℃
Capacity: approx.100/ 200/300 cassettes
Reagent volume (in liters): 5.3
Temperature (paraffin): 65 °C
Temperature (processing reagents): ambient or 35°C
Temperature (cleaning reagents): 65 °C
Temperature accuracy: + 3 °C
Filling time: 5 min
Drain time: 5 min
Impregnation pressure: 35 kPa (g)
Drain pressure: 35 kPa (g)
Reagent bottles: 10
Cleaning solution bottles: 2
Maximum bottle volume: 4.0 l
Recirculation (pump in/out): ON/OFF
Time between cycles: 20 min
Large color Liquid Crystal Display (LCD) User-friendly, intelligent software.
Alarm system to reminder wrong operation and trouble
Multiple specimen protection system.
20 programs that consist of up to 9 reagent and 3 paraffin wax steps.
Time per program step: 0 to 99 hours, 59 minutes.
Up to 100/200/300 cassettes can be processed simultaneously.
Wax clean program.
Nominal frequency: 60HZ
Main fuses: 10A
Nominal power: 1000 VA
Dry weight, unpacked: approx. 100 kg
Weight, packed: 130 kgs/ 165kgs/172kgs
Operating temperature range: 15 °C to 35 °C
Relative humidity: 10 % to 80 %, non-condensing

Standard Accessories:
10 reagent bottles.
3 wax baths.
2 cleaning solution bottles.
2 condensate bottle.
Standard Setting List
Tissue Bakset 1 pcs
Reagent Bottle 17 pcs
Fuse (10A) 2 pcs
Power line 1 line
Tissue Basket
Regent Bottle

Package Info:
Each instrument packed Wooden Case
Outer Case Dimensions (for 3kinds capacity machine): 700*680*1390mm / 800*740*1460mm/ 800*740*1460mm,
Gross Weight: 130kg/165kg/172kg
