MANUAL CRYOSTAT MICROTOME

(Freezing Microtome)

Model No. – MCM-1090a

Make – WESWOX

SPECIAL FEATURES :

The cooling system incorporates PID temperature controller and a sealed compressor to

ensure quick cooling up to -30deg C and trouble free performance. Large stainless steel

chamber permits adequate storage facilities for housing of microtome. Visual display for

section thickness indication. Lateral displacement feature provided for blade.

TECHNICAL SPECIFICATIONS:

Section Thickness Range: 1µm-35µm in 1µm increments.

Minimum Setting Value: 1µm

Vertical stroke: 65mm

Specimen horizontal feed: 25mm

Temperature range: up to -30deg C.

Supplied complete with a razor 120mm long.
