(with built-in Halogen lamp & KEOWA optics)
(Pathological Binocular Microscope with Co-axial Focusing)
|Model No. – JXi-500||Make – WESWOX|
OPTICAL SYSTEM : Universal Infinity corrected Optical system
STAND: Stable & sturdy C shaped stand with well-contoured modular base, corrosion resistant paint and heat resistant pads. Extended base for better stability.
VIEWING HEAD: Siedentopf Binocular/Trinocular tube, inclined at 30° rotatable through 360° with IPD 55-75 mm. Anti fungus treated.
EYEPIECES: Focussable Eyepiece WF 10x FN 22 paired with eye guards, anti-fungus treated.
NOSEPIECE: Low friction & fully parafocal Reverse angle quadruple Revolving nosepiece (Ball bearing type) with click stop & rubber grip.
OBJECTIVES: KEOWA BJ series All New High Definition Infinity Plan DIN parafocal Plan Achromatic lenses, Anti fungus treated objetives:
PLAN ACHROMAT 4x/0.10
PLAN ACHROMAT 10x/0.25
PLAN ACHROMAT 40x(SL)/0.65
PLAN ACHROMAT 100x(SL, Oil)/1.25.
FOCUSING: Ergonomic low position co-axial coarse and fine focusing system on ball bearing guideways. Tension MODULE adjustment ring provided. Fine Graduation 2-3 micron.
STAGE: Ceramic coated rackless Double layer graduated mechanical rectangular stage size 140 x 132mm wire cross travel 75 (X) x 50 (Y) mm on ball bearing co-axial controls spring clip specimen holder.
CONDENSER: Movable ABBE condenser, with aspheric lens NA 1.25, daylight blue filter & Iris diaphragm. Centrable
ILLUMINATION: Koehler Illumination, Super Bright White LED cold Light, Optional 6V 20W Halogen Lamp
POWER: Universal Power Supply 100 V to 240 V,AC 50-60 Hertz, CE Compliant.
The microscope is packed inside a STYROFOAM box with Dust Cover.
Styrofoam molded box, dust cover, instruction manual, and fuse.
Upgradeable to Fluorescence attachment with battery backup.
